Single Row Taper Roller Bearings NSK HR32040J Bearing is one kind of taper roller bearing design. Its dimension is 25×52×16.25mm,weight is 0.15kg, the material are adopt high quality chrome steel , this design are separable. the bearing ring with the rollers and cage assembly can be separated from the other ring, so this kind of bearing are the same with single row cylindrical roller bearings.

Taper Roller Bearings also have the other different design as follows

--Metric Single Row Taper Roller Bearings

--Inch Single Row Tapered Roller Bearings

--Double Row Taper Roller Bearings

--Four Row Taper Roller Bearings

--Hub bearing units for trucks

NSK HR32040XJ bearing is Tapered roller bearing and commonly type and widely used in many application like the spindle of machine , it contains inner ring, outer ring , and steel cage,tapered roller bearing can carry radial and axial loads in both directions , NSK Taper roller bearings are particularly versatile and are simple in design , separable , NSK HR32040XJ bearing suitable for high and middle high capacity , but low cost maintenance . as one of the biggest top quality bearing brand , Quality can be approved by the market .

Technical Features Of NSK Taper Roller Bearing

Boundary Dimensions: In accordance with ISO 355-1977 DIN 616 (large bearings)

Tolerances : Normal, with O/D over 420 mm the running accuracy is P6

Heat Stabilization : Bearings up to 165mm O/D 302°F (125°C) 166-420mm O/D 392°F

(150°C)

Misalignment : 3 minutes of arc (logarithmic profile rollers)

Cage Material :

Standard : Steel Cage

Optional : None

Axial Load – max : Contact XRB Application Engineering

Seals : Not available

XRB has a wide range of tapered roller bearings consisting of detachable elements that make them easily adjustable in applications.

The most popular applications for this bearing type are :

· Wheel hubs for light, industrial, and agricultural vehicles

· Transmissions (gearboxes and differentials)

· Machine tool spindles

Application Of Single Row Tapered Roller Bearings

XRB is the China bearing manufacturer,exporter, supplier, it can supply NSK HR32040XJ bearing, Our large quantity Single Row Tapered Roller Bearing Stock can meet your need with good quality and fast delivery, Also you can find FAG 32040X Bearing, the other type and brand tapered roller bearing. just like NTN . NKE . ZWZ . TIMKEN . We accepted DHL , FEDEX , TNT express for small order and samples order , also the transportation By AIR or By Sea , by Train are all avaiable.we asure we can ship high quality NSK HR32040XJ bearing to your office at the first time .
